SSD Drives 591P Series - 1250A Single or Two Quadrant DC Thyristor Drive for 220-500V 3ph Supply with universal 115-230V 1ph Control circuit.
Typical Motor output - up to 600kW (800HP) at 500V DC, for DC motor speed and torque control.

Simple to set-up in Digital, fully-isolated Single or Two Quadrant form.
Size 6: 686mm Wide x 497mm Deep x 715mm High.

Terminals include:-
5 x Analogue Inputs (4 x Configurable).
3 x Analogue Outputs (2 x Configurable).
Tacho input (or internal AVF) Feedback.
10 x Digital inputs - 5 are Configurable including two as encoder inputs for a second or line encoder.
3 x Digital Outputs (all Configurable).
+ & - 10V for Potentiometers.

Input Current - xA for Armature + up to 60A for Field.
Input Voltage - 220-500V ac ±10%, 50/60Hz ± 5%.
Control supply at 115-230V single phase is required for; electronics, pilot for main contactor and 300W cooling fan, flc is 3A at 115V, 1.5A at 230V.

Rated at 40C Ambient.
Heat Loss at max output - 4600W.

Full part number is - 591P-53412560-P00-U4A0.

Includes 3 x 700A high speed limb internal (arm) fuses.
(Thyristor I*t = n/a)
